SKYRICH LTM7L LITHIUM ION BATTERY WITH VOLTAGE DISPLAY AND OVERCHARGE PROTECTION

Skyrich is a premium manufacturer and series supplier for well-known manufacturers such as KTM and Ducati.

The LTM-Line Power Sports lithium-ion batteries feature a heat-resistant, waterproof nylon case and improved terminal connections.

Overcharge Protection (OP)

The Skyrich battery features an advanced Battery Management System (BMS), which includes overcharge protection in addition to the balancers (ensures even charging/discharging of the battery). This prevents the battery from being charged with a voltage above 14.9V.

Spacer (S)

Battery is equipped with one or more spacers, which are glued under the battery with the supplied adhesive strip, so that the battery fits exactly into the battery box.

Waterproof (WP)

The battery is completely waterproof and will not take damage when the motorcycle is cleaned with high pressure.

Indicator (I)

All batteries are equipped with an improved state of charge indicator, which shows the battery's state of charge even more precisely.

Replacing a standard lead-acid battery with a Skyrich lithium-ion battery can save up to 5 kg of weight, without significant effort.

The following advantages speak for Skyrich Lithium-Ion batteries:

- integrated overvoltage protection
- approx. 1/3 of the weight of the comparable lead-acid battery
- improved brass terminal connections for best conductivity
- waterproof
- completely black battery housing
- battery housing made of nylon, so deformation due to heat is practically impossible
- unbeatable cost/weight ratio of lithium-ion batteries.
- can be installed in any position as it contains no acid
- contains no heavy metals
- balanced discharge/charge of all cells by balancer
- fast charge with high charge current possible (up to 90% in 6 min)
- very low self-discharge (max. 5% per month)
- even at high temperatures still good performance up to 60°C
- safe technology and long life

Lead-acid batteries can only use 30% of their capacity due to their specific characteristics, while lithium-ion batteries can use almost 100% of their capacity.

For this reason, the lithium versions of Skyrich batteries require only 1/3 of the capacity of a comparable lead-acid battery for the same starting power.

With the help of adapters, the dimensions of the lithium-ion batteries correspond to the dimensions of the original lead-acid batteries.

The connections are also identical, which is why the battery can be replaced in a few minutes without any further adjustments.

Please note that only suitable chargers may be used for charging. We recommend JMP chargers.
Please refer to the technical data below for the maximum recommended charging currents.

Under no circumstances should chargers be used that attempt to desulfate deeply discharged batteries below 10 volts with a voltage greater than 14.9 volts before beginning the actual charge.

The manufacturer guarantees sufficient starting capacity down to -5 degrees Celsius.

Technology
Skyrich lithium-ion batteries use iron phosphate (LiFePO4) as the cathode material and use the lithium polymer process in their manufacture. As a result, they cannot burst into flame or explode during normal operation.
The technology and manufacturing process ensure the highest safety standard for lithium batteries.

- 12 V maintenance-free lithium-ion battery

- charging current recommended 1 A

- maximum charging current for fast charging 10 A

Identical in construction with:

YB6.5L-B

12N7A-3A

YB4L-A

YB4L-B

12N5.5-3B

12N7D-3B

YTZ5S

12N7-3B

YTX7L-BS

12N7CZ-3D

YTX5L-BS

12N4-3B

YB5L-B

YB7L-B

YTZ7S

12N5-3B

YTX4L-BS
